CRE 18
ANNULAR UV PHOTO REACTOR
The set-up is used to study a photo / photocatalyc reaction using a UV source provided in the form of an UV tube. This set -up can be used to carry out a parameter study under batch/continuous flow condition. A photo catalyst like TiO2 can be used. This set-up can also be used to study the mineralization of liquid effluent industrial streams & for purification of water. The set-up consists of reactor with inside reflecting surface. An UV source surrounding glass/quartz cylinder is placed centrally in the reactor.
UTILITIES REQUIRED
- Water supply and drain
- Electricity-0.5 kw, Single
- Instruments, Laboratory wares and Chemicals required for analysis as per the system adopted
| Product & Code |
Annular UV Photo Reactor & CRE 18 |
| UV Source |
30 W / 16 W |
| Reactor |
With inside reflective surface
Effective ,volume of reactor 1 – 1.5 Ltrs. |
| Feed Tank |
Material Stainless Steel, Capacity 5 Ltrs |
| Feed circulation |
Magnetic Pump made of Polypropylene. Maximum working temperature is 80°C |
| Flow Measurement |
Rotameter |
| Control panel |
On off switch, Mains Indicator, fuse, power supply to UV source etc. |
| Sampling points are provided at inlet & outlet of reactant line. |
| The setup is painted with good quality paints & mounted on a strong support. |
